Build the garage you actually want, not the one your storage boxes have taken hostage. This extra-high storage lift helps move bulky gear up and out of the way so your floor stays open for cars and the projects that make garage life fun. It is a smart fit for tall garage bays where ladder trips with heavy bins are getting old fast. If you want a clean, motorized answer for overhead storage, this attic lift system brings serious convenience without turning your ceiling into a science project.

Specifications

• Powder coated steel frame
• Lifting Capacity: 200 lbs max
• Lift Speed: 8 in/sec (8 ft in approx 12 sec)
• Cables (2): .093 steel 1,000 lb break
• Motor: .6 hp, 1725 rpm
• Voltage: 110 v AC
• Power: 4.5 amps, 560 watts
• Remote Control: Hand-held with 15 ft cord
• Remote key included for safety of operation
• Units are not intended or approved for lifting persons
• 26" wide by 56" long by 46.25" high
• Weight: 170 lbs
• 48" attic floor to roof rafters required
• Max Ceiling Height: 19 ft
• Max Joist Height: 18"
• Max floor-to-floor: 14-17 ft
• Opening size: 22.5" x 46.5"
• Framing: 24" x 48"

Fit and Planning Notes

Before ordering, compare your garage and attic layout against the opening, framing, joist, ceiling, and rafter requirements above. This lift system is made for people who have usable overhead space but would rather keep the main garage area dialed in, walkable, and ready for the next wrenching session. Seasonal bins, bulky supplies, and the stuff that always seems to drift into your parking spot can finally have a better place to live.

Operation and Safety

The control setup keeps day-to-day lifting straightforward, while the included safety details help you manage access and use with confidence. Plan your loads, measure carefully, and review the installation information before you cut, frame, or schedule the job.

For additional specs and information about installation, click here

For a clean overhead storage upgrade, this is the kind of garage storage lift that makes the whole space feel more organized. It clears the clutter, saves ladder hassle, and helps your garage work the way you always wanted it to.
