Adjustable Radiant Tube Garage Heater, 37,500-75,000 BTU

Turn a cold garage into a place you actually want to work with this adjustable radiant tube heater for garage and shop comfort. Instead of just stirring cold air around, infrared heat warms the tools, cars, floor, and workbench you are working around, so the space feels more usable during serious garage time. It is a strong fit for gearheads, hobbyists, vehicle maintenance, and anyone who wants steadier heat in an attached garage. The result is a shop that feels ready when you are, whether you are knocking out winter projects or just keeping the chill off your favorite space.

Specifications

• BTU output: 37,500-75,000 BTU.
• BTU output adjustment: manual adjustment so you can heat the garage fast, then turn it down once you are comfortable.
• Heater size: 20 feet long by 15 inches wide.
• Designed coverage in insulated spaces: 27' x 36' (972 sq. ft.) up to 40' x 40' (1,600 sq. ft.).
• Insulation requirement: minimum R-12 in walls and roof.
• Non-insulated garage note: will use more fuel and feel cooler than an insulated garage.
• Thermostat, modulating control, and hanging kit included.
• Low-voltage thermostat connection.
• Certified for indoor and outdoor use.
• Venting: through the roof or wall.
• Meets low-clearance requirements.
• Multiple units can be grouped to achieve the length you want.
• Available in various lengths and configurations.
• Uses 30%-40% less energy compared to conventional heating systems.
• Quiet, draft-free operation.
• Melts snow and ice from vehicles to keep floors warm and dry.
• Sleek, architectural design.
• Creates comfortable space for hobbies, vehicle maintenance, pets, crafts, and more; also provides helpful heat for homes with attached garages.

Included Equipment and Construction

• Pre-assembled, prewired burner control housing.
• Industry-standard gas, electrical, and venting connections.
• Balanced air rotor and thermal overload protection motor.
• Visual burner inspection sight glass.
• Combustion and air proving safety switch.
• 3-Try Direct Spark, electronic ignition system with 100% safety shut-off; no standing pilot, no valves to turn, and no thermocouples to replace.
• 4" heat-treated aluminum combustion tube.
• Aluminum reflector and 4" mild steel radiant heat exchanger.
• Tube couplers, joint/hanger pieces, and heat economizer baffle.
• Heavy-duty construction with high-quality stainless steel workmanship.
• Eight-sided aluminum reflector with anti-walk design prevents shifting or twisting during expansion and contraction and remains stable through temperature changes.
• Utilizes the largest and heaviest gauge reflector in the industry.

Gas Type Options

This heater is sold in both Natural Gas and LP Gas configurations. Select the gas type from the dropdown at purchase so the unit matches the fuel setup you plan to use in your garage or shop.

Helpful Resources

• Instruction Manual
• Garage Heater Brochure

When the temperature drops, this gas infrared tube heater keeps your workspace moving without turning the garage into a wind tunnel. Choose the configuration you need, hang it up, and get back to enjoying your garage instead of just surviving it.
