50,000 BTU Propane Radiant Tube Garage Heater with Thermostat

Keep the garage usable when winter tries to shut the project down. This 50,000 BTU propane radiant tube heater for garage spaces delivers infrared heat that warms the surfaces you actually work around - the floor, tools, vehicles, walls, and people - instead of just blasting air around the room. That means quiet, draft-free comfort without blower noise, which is exactly what you want when you are wrenching, detailing, or just hanging out in the shop. If you have an insulated garage and want a clean overhead setup, this is a serious upgrade.

Radiant tube heat is a favorite for gearheads because it helps the whole space feel steady and comfortable, not hot in one corner and cold everywhere else. It is designed for low-clearance installs and slim overhead mounting, with venting through the roof or wall to fit your layout. Multiple units can also be grouped to reach the length you want, making it a flexible choice for garages and shop spaces that need dependable heat.

Specifications

• Heat Output: 50,000 BTU
• Fuel Type: Propane
• Heater Type: Low-intensity infrared radiant tube heater
• Coverage Area: From 25' x 26' (about 650 sq. ft.) up to 27' x 32' (about 864 sq. ft.)
• Recommended Insulation: Garage insulated to at least R-12 in the walls and roof
• Non-Insulated Garage Note: A non-insulated garage will consume more fuel and will feel cooler than an insulated garage
• Overall Size: 15 feet long by 15 inches wide
• Certified for indoor and outdoor use
• Venting: Through the roof or the wall
• Installation Style: Designed for low-clearance installs and slim overhead mounting
• Thermostat and modulating control included
• Hanging kit included
• Uses 30%-40% less energy than traditional heating systems
• Helps melt snow and ice off vehicles to keep the floor warm and dry
• Available for use with natural gas or propane

Standard Equipment

• Pre-assembled, prewired burner control housing
• Industry-standard gas, electrical, and venting connections
• Balanced air rotor
• Thermal overload protection motor
• Visual burner inspection sight glass
• Combustion and air proving safety switch
• 3-Try spark ignitor control with direct spark electronic ignition - no standing pilot, no valves to turn, and no thermocouples to replace
• 100% safety shut-off
• Low voltage thermostat connection
• 4" heat-treated aluminum combustion tube
• 4" mild steel radiant heat exchanger
• Heavy-duty construction, including high-quality stainless steel
• Eight-sided aluminum reflector that resists warp and stays put during expansion and contraction
• Tube couplers
• Joint/hanger pieces
• Heat economizer baffle

Resources

• Instruction Manual
• Garage Heater Brochure

This propane infrared tube heater gives your garage the kind of steady, no-nonsense heat that keeps projects moving after the temperature drops. With thermostat control, included hanging hardware, and flexible venting options, it is built to make cold-weather shop time a whole lot more comfortable.
